GROUT TUBE & CONNECTORS
Data sheet DS58E
Grout tube and connectors
Range of sizes available
Designed and manufactured in the UK
CONNECTORS
| PART NO. | DESCRIPTION | CONNECTOR TYPE | MATERIAL | COLOUR |
|---|---|---|---|---|
| GC018S=00000 | GROUT CONNECTOR 18 | IN LINE | POLYPROPOLENE | BLACK |
| GC019/23E=00000 | GROUT CONNECTOR FOR OVM ANCHOR | 90˚ | POLYPROPOLENE | BLACK |
| GC019E=00000 | GROUT CONNECTOR | 90˚ | POLYPROPOLENE | BLACK |
| GC019S=00000 | GROUT CONNECTOR 19 | IN LINE | POLYPROPOLENE | BLACK |
| GC019S-HD=00000 | GROUT CONNECTOR 19 | IN LINE | POLYPROPOLENE | GREY |
GROUT TUBES
| PART NO. | DESCRIPTION | INTERNAL DIAMETER (mm) | EXTERNAL DIAMETER (mm) | COLOUR |
|---|---|---|---|---|
| GCT12.00 | ELLIS GROUT TUBE - 12.0mm ID | 12 | - | WHITE |
| GCT13.20-BL | ELLIS GROUT TUBE - 13.2mm ID, 17.0mm OD | 13.2 | 17 | BLUE |
| GCT16.8-B | ELLIS GROUT TUBE - 16.8mm ID, 20.0mm OD | 16.8 | 20 | BLACK |
| GCT17.60 | ELLIS GROUT TUBE - 17.6mm ID, 22.2mm OD | 17.6 | 22.2 | WHITE |
| GCT18.65 | ELLIS GROUT TUBE - 18.65mm ID, 22.0mm OD | 18.65 | 22 | WHITE |
| GCT18.65-BL | ELLIS GROUT TUBE - 18.65mm ID, 22.0mm OD | 18.65 | 22 | BLUE |
